SINGLE-ARM LIFT
VERTICAL LIFT ROBOT // RM65-B-V
precision_manufacturing
RM65-B-V Arm
Integrated RM65-B-V robotic arm with 5kg payload capacity for precise single-arm manipulation tasks.
height
900mm Vertical Lift
900mm effective lifting stroke enables flexible height adjustment for multi-level operation scenarios.
radio_button_unchecked
Compact Circular Base
505mm diameter omnidirectional base with 252.5mm turning radius for tight-space navigation.
my_location
Autonomous Navigation
Autonomous path planning with <±5cm positioning accuracy for reliable cross-scenario deployment.
storefront
Cross-Scenario
Broad applications spanning new retail, logistics, industrial, commercial, home, and research settings.
PHYSICAL & PERFORMANCE
Overall Dimensions
H1605 / D505 MM
Total Weight
~100 KG
Single Arm Payload
5 KG
Lifting Stroke
~900 MM
Movement Speed
1 M/S
Turning Radius
252.5 MM
Positioning Accuracy
<±5 CM
Robot Arm Model
RM65-B-V
SYSTEM & POWER
Charging Supply
100-240VAC 50HZ
Power Supply
DC 24V
Endurance
3 HRS
Operating Temp
5~40°C
Core Capability
FULL-BODY CONTROL
Applications
RETAIL / LOGISTICS
Navigation
AUTONOMOUS SLAM
Manipulation
PRECISE SINGLE-ARM
